PES membrane is cast from polyethersulfone. It has asymmetric pore structure through the cross-section, which ensure both high flow rate and high retention. PES has characteristics like hydrophilicity, low protein binding and low extractables, thus suitable for biological and pharmaceutical applications.

Membrane

PES

Wettability

Hydrophilic

pH

1-14

Water Flow rate

0.22μm：≥10mL/min/ cm2@1 bar(14.5 psi)

0.45μm：≥20mL/min/cm2@1 bar(14.5 psi)

Bubble point@23 °C（water）

0.22μm：≥3500mbar(50.7psi)

0.45μm：≥2500mbar(36.25psi)

Pore Size

0.1, 0.22, 0.45,0.65, 0.8, 1.0,3.0, 5.0μm

Color

White

Surface

Plain

Dimension

Φ13, Φ25, Φ47, Φ60, Φ90, Φ142, Φ150mm

Max. Differential Pressure

Forward：4.2 bar @ 23℃(60.9psi@73.4℉); 1.5 bar @ 85℃(21.7psi@185℉)

Non-Fiber Releasing

Conform to criteria for a “non-fiber releasing” filter as defined in 21 CFR 210.3(b)(6)

Sterilization

123℃(253.4℉) autoclaving or EO
